Telcoma Automations T10 FM400 User Manual

Mor. n. Mor. n. Device V I max. Function
1 2 Line 230 Vac 2,5 A Control unit power supply 3 4 F1
230 Vac 2,5 A Open (or Close) Motor / Light 1
4 5 F2
230 Vac
2,5 A Close (or Open) Motor / Light 2
6 7 P1 Control button 1 (NO normally open contact) 7 8 P2 Control button 2 (NO normally open contact)
Earth terminal Earth terminal
TERMINAL
1 2 3 4 5
6 7 8
COM.COM.
F1F1
230 V
50/60 Hz
F2F2
P1 P2
Function Open Close
Rolling code
(T10 NOIRE)
Motore/Luci
X
X
Motor
inversion
X
X
Open-close/step-
by-step-clock
buttons
X
X
Description Rolling code disabled Rolling code enabled MOTOR mode LIGHT mode Standard motor output Reverse motor output (closing this jumper the motor will rotate in reverse P1 Open (or Close) button, P2 Close (or Open) button, P1+P2 STOP command P1 clock input, P2 Step-by-step button
JUMPER
F1 F2 F3 F4
Light timer
(LIGHT mode)
X
X
Standard light output (on/off) 30 Second timed light output
P1, P2 buttons
mode (LIGHT
mode)
X
X
P1 Light 1 ON/OFF button - P2 Light 2 ON/OFF button P1 Lights 1 and 2 ON - P2 Lights 1 and 2 OFF
GB
GB
26
27

Telcoma Automations T10 FM400 Specifications

General

Brand	Telcoma Automations
Model	T10 FM400
Category	Control Unit
Language	English
