CHARACTERISTICS AND PARTS DESCRIPTION
EVOseriesgearmotorsare extremely versatile units for theautomationof sliding gates upto 1200Kg.
This manual covers three models with different powers and gear reducers but the same dimensions and installation procedure;
electricalconnectionsandprogrammingare also standardised.
1.motorcover
2.magneticlimitswitchsensors
3.pinionguard
4.pinion
5.sidecovers
6.ECU
7.ECUsupport
8.transformer
9.motorheightadjustmentstudbolt
Partsdescription(fig.A)
TECHNICAL DATA
Power supply voltage
Motor voltage
Max. motor current
Max. absorbed power
Protection class
Maximum torque
Max. thrust force
Max. gate speed
Operating temperature
Duty cycle intensity
Weight
MOTOR
Max. torque during the starting
Max. gate weight
Encoder
Control unit power supply
YES YES YES YES
Magnetic limit switch YES YES YES YES
Control unit
230Vac
EVO600U.M.
Vac 230
A 3,5
W 800
Nm
540
21
N
m/min 10
40
EVO800
3,5
800
640
24
10
60
EVO1200 EVO1200R
5,5 5,5
1100 1100
1200 1200
45 45
10 10
60 60%
µF 16 20 20 20
Kg 600* 800* 1200* 1200*
44
YES
IP
°C -20 +55
YES
9,5
TS10
/
10
/
TS20
10 10,5
/ /
TS40 TS40
Kg
Vac 230 ± 10%
YES
T101mod.
10.motorfixingcrews
11.motor release lock
12.motorreleaselever
13.motor
14.encoder
15.oilbleedscrew (EVO800/1200/1200R)
16.oilplug(EVO800/1200/1200R)
17.motorconnection(EVO800/1200/1200R)
18.bracketswith limit switch magnet
Heater power supply
Max. heater output
Heater t.on/t.off
/
/
/
/
/
/
/ 110-230
/ 20
/ 4-5/10-12
Vac
W
°C
Electronic deceleration
Electronic motor brake
Grease lubricant
Oil lubricant
Electronic torque limiter
(*)Max.weightofdoorinsmooth and balanced operating conditions on opening and closing.
These application limits CANNOT be guaranteed if using NON conforming doors, or components that are worn and not
subjectto thecorrectmaintenance.
PRELIMINARY CHECKS AND IMPORTANT SAFETY NOTES FOR INSTALLATION
Beforeproceedingwithinstallation,checksshouldbe made on:
1. thesolidityofthe existing structure (posts, hinges and leafs) in relation to the forcegeneratedby themotor.
2. theprovisionof mechanicalstopsof suitable strengthattheends of the gateopeningand closing strokes.
3. thebottomwheel/railsystemandupper roller/guide system to ensure there is no rubbing or excessiveclearance.
4. thedisablingof any manuallocks.
5. theconditionofanywiring alreadyinstalled in the system.
