Getting started
English - 51 -
You may use a VGA-compatible YPbPr cable (not provided) to enable the YPbPr signal via the VGA port.
|You will no longer be able to use the VGA and YPbPr simultaneously. | For the YPBR or PC port, you have
to connect the audio output of your device to the television’s audio AV input. |When an external device is
connected to the jack socket of your TV, the TV will enter AV mode automatically when you turn on the external
device .|When you are in digital mode (tuner, usb, hdmi) you will not have audio-video signal output through the
jack socket. |If you use a wall-mounted kit,un , it is advisable to connect all your cables before fixing your TV to
the kit. |Insert or delete the CI module CI only when the television is off. Consult the module’s instruction manual
for more information on its settings.
Connector Type No cable or accessory provided Device
External
device
Connection
(behind)
VGA
Connection
(behind)
AV ON THE
SIDE
PC/YPbPr
Audio
Connection
(side)
YPbPr audio connection cable
(not supplied)
HDMI
Connection
(behind)
SPDIFF
Connection
(behind)
AV ON THE
SIDE
Lateral AV
Audio / Video
Connection
(side)
(not supplied)
HEADPHONE
Headphone
Connection
(side)
YPbPr Video
Connection
(behind)
USB
Connection
(side)
CI
Connection
(side)
CAM
module
12V
DC IN
DC 12 V Input
V+
V+
V-
V-
