4. DESCRIPTION OF WFT400
The WFT400 router is for internal use and allows the connection of multiple devices, such as comput-
ers, smartphones and smart TVs, to the Internet via a SIM CARD (not included).
Descriptions of the router’s connectors and controls are provided in the gure.
8
7
6
5
9 10 11 12 13
1414
1 3 4
Fig. 1 - Description of connectors and controls
1 USB port 8 WPS button
2 NA 9 ON/OFF LED
3 WAN/LAN port 10 RF signal strength LED
4 Power supply 11 WiFi signal LED
5 SIM CARD slot 12 LAN cable connection LED
6 ON/OFF switch 13 Internet connection LED
7 Reset 14 SMA connector for external antenna (external antenna not
supplied)
