TDMC+ Teledyne Dual Mode Charger
Questions? Write to: support@teledynebattery.com Page 13/15
Or call: 1 (800) 456 0070 / 1 (909) 793 3131.
Charging Specifications
General Parameters
12V Specification
24V Specification
Maximum Charging Current
6A +/- .5A
Standby battery Drain
<100 uA with AC disconnected
Voltage Regulation
+/- .5%
Output noise and ripple
<150mV, 100MHz BW
Efficiency
Minimum 85% under worst line/load conditions
3 Stage Parameters
12V Specification
24V Specification
Max Absorption Voltage
14.4V +/- 100mV
28.8V +/- 100mV
Absorption to Float Current
500mA +/1 100mA
500mA +/1 100mA
Float Voltage
13.15V +/- 100mV
26.30V +/- 100mV
Overvoltage Protection
15.2V +/- 200mV
30.4 +/- 200mV
2 Stage Parameters
12V Specification
24V Specification
Duration of Stage 1 + 2
10 – 80 hours, selectable
Max Absorption Voltage
15.0V +/- 100mV
30.0V +/- 100mV
Unit Specifications
Electrical Input
Voltage
85 VAC – 270 VAC, 50/60 Hz
Max Power
250 Watts
Configuration
Line, neutral, chassis ground
Connector
IEC 60320 C14 power inlet (C13 cord plug)
Supplied Cable
18AWG grounded cord with NEMA 5-15
grounded Type B wall connector
Electrical Output
Voltage
32 VDC maximum
Current
6A maximum
Configuration
Positive, Negative
Connector
Two pin circular
Supplied Cable
14 AWG battery cord with crocodile style
battery clips
Environment
Orientation
May be used horizontally or vertically
Location
For indoor use only.
Operation
-22F to 140F (-30C to 60C)
Storage
-40F to 176F (-40C to 90C)
Certification
UL (U.S)
Under Evaluation
CUL (Canada)
Under Evaluation
CE
Under Evaluation
FCC
Compliant to Part 15 of FCC Rules
Mechanical Dimensions
(unit only)
Height
11.5” (290mm)
Depth
5” (130mm)
Width
6” (150mm)
Weight
6 lbs (2.7 Kg)
