LED Indicators
Four Red/Green indicators provide an easy way to monitor the operation of the charger from a
distance.
• Status
• Off – Not Charging / Charger is idle
• Red – Stopped on Error
• Red/Green – Charging
• Green – Charge Complete
• Connection
• Red – Battery is reverse polarity
• Red/Green – Battery not detected
• Green – Battery is connected correctly
• Charge Stage
• Off – Not Charging / Charger is idle
• Red – Constant Current
• Red/Green – Constant Voltage
• Green – Float
• Fault
• Red – Fault detected, unit requires service
• Red/Green – Over temperature, allow unit to cool before use
• Green – No faults detected
Status
Connection
Stage
V
C
Fault
