TDMC+ Teledyne Dual Mode Charger
Questions? Write to: support@teledynebattery.com Page 4/15
Or call: 1 (800) 456 0070 / 1 (909) 793 3131.
• Quick Start
• Plug in charger, ensure charger shows “not Charging” in Idle Screen Section F.
• Connect battery, verify voltage in Section E has changed.
• Select Charge Voltage (Press button in Screen Section A), Charge Current (Screen Section B)
and Charge Cycle End Condition (Press button in Screen Section C).
• Press Go! (Press button in Screen Section D)
• Screen Section F will show “Charge Complete” when the charge cycle ends successfully.
Product Description
The Teledyne Battery Products TDMC+ is a battery charger for 12V and 24V lead-acid batteries. It
offers two microprocessor-controlled precision charging method: a three-stage charging method for
normally discharged batteries, and a two-stage charging Method for recovering sulphated or overly
discharged batteries.
The charger offers an internationally recognized AC input connector, wide input voltage range
operation, wide operating temperature operation, a sealed chassis with external convection-cooled
heat fins, reverse polarity detection, temperature and voltage protection and integrated voltage and
current monitor. The TDMC includes a battery connection cable with crocodile clips for a wide variety
of battery terminals.
