Telefunken TF32K82A - Page 56

Parts List (For Reference Only) (TF37A82H)
Item Part No. Description Location
1 E0002-002022R0 TOROIDAL FERRITE T22.5*10*13.8 (RoHS)
2 E0002-001005R0 BATTERY R03P MERCURY-FREE (RoHS)
3 E0002-103004R0
SHRINKABLE TUBE S-901(FLAME-REDARDANT) 125℃VW-1
Φ2.0 (Φ
2.5 TO Φ1.0)
(RoHS)
4 E0002-103008R0
SHRINKABLE TUBE S-901(FLAME-REDARDANT) 125
℃
VW-1
Φ
4.0 (
Φ
4.5 TO
Φ
2.0)
(RoHS)
5 E1302-003006R1 CAP EC NP V CD71-BP T05 1R0M 50DC 5×11 (RoHS)
6 E3202-001036R1 JACK AC POWER SOCKET TU-301-A-A 3PIN 180° (RoHS)
7 E3404-001027R2
AC CORD VDE VH3.96-3Y Φ4.2 3×0.75mm² 2.5A 640mm (RoHS)
8 E3405-001064R0 AC CORD EUROPEAN Y003+H05VV-F 3× 0.75mm2 +ST3 L= 2000mm (RoHS)
9 E3421-002328R1 WIRE ASSY PH-4Y UL2468 #22 L=960/460mm 2.0mm/ 4P (RoHS)
10 E3421-002362R1
WIRE ASSY PH-9Y/PH-5Y/PH-4Y UL2547#26 L=580/660mm 2.0mm/2.0mm/2.0mm
9P/5P/4P （RoHS）
11
E3421-002387R0
WIRE ASSY PH-6Y/PH-5Y UL2547#28 L=
700
mm 2.0mm/2.0mm 6P/5P （
RoHS）
12 E3421-002480R0 WIRE ASSY TJC3-10Y PH-14Y/3Y UL2468#22 L=600/300mm 14P/10P/3P (RoHS)
13 E3421-002415R0
WIRE ASSY TJC3-4Y/2Y UL2468#22 L=250mm 2.5/2.0mm 4P/2P （RoHS）
14 E3421-002416R0 WIRE ASSY TJC3-11Y/11Y/10Y/7Y UL2468#22 L=220/180/180mm 11P/11P/10P/7P (RoHS)
15 E3421-004045R0 WIRE 22# L=150mm RED/BLACK 2P (RoHS)
16 E3421-004046R0 WIRE UL1672#18 L=380mm 1P BLUE (RoHS)
17 E3421-004047R0 WIRE UL1672#18 L=380mm 1P BROWN (RoHS)
18 E3421-006057R1
WIRE ASSY 2.0-2X15P/JAE FI-X-30P(WITH LOCK) L=290mm 2.0mm/1.0mm 30/30p
(RoHS)
19 E3422-001020R0 WIRE AV RCA M*3/RCA M*3 S518-02-001 L=1500MM 3P (RoHS)
20 E4101-001018R0 SWITCH POWER KND3-B31 (RoHS)
21 E5501-001051R1 ADAPTER VP192UG01-GP 5Vsb/0.5A 5V/4A 12V/2A 24V/5A 24V /1A (ROHS)
22 E5601-001040R0 SPEAKER 8OHM 15W (RoHS)
23 E5601-001042R0 SPEAKER YDG50-1 8OHM 3W (RoHS)
24 E6101-001115R0 TFT-LCD LC370WX4-SLA1 LG-PHILIPS (RoHS)
FOR REFERENCE ONLY
The components shown in the remaining pages served as a reference only. It is not meant for ordering of
componesnts for servicing purposes.Do not quote any components from these lists.
ELECTRONIC COMMON PART ASSEMBLY(FOR FSP ADAPTER) (RoHS)
