Telefunken TF32K82A - DRIVE PCB Assembly Parts

Parts List (For Reference Only) TF32K82A TF37A82H
Item Part No. Description Location
1 E1101-001025R1 COIL FIX H AL0204S T52 220J (RoHS) L52 L20 L21
2 E1111-002019R1 COIL FIX CHIP CMI1608VBP 2R2M 0603 (RoHS)2.2uH L31 L32 L59 L62
3 E1111-003018R2 COIL FIX CHIP CMI2012VTP 1R8K 0805 (RoHS) L54 L53
4 E1111-014004R1 FB FIX CHIP CBY160808UBP 190 0603 (ROHS)
FB1 FB2 FB3 FB4 FB6 FB7 FB8 L17
L18 L19 L23 FB23 L24 L25 L26 L27
L28 L29 L30 FB31 L33 FB33 L34 L57
L60 L63 L64 L65 L66 L67 L76 L77
L78 L79 L80 L81
5 E1111-015003R1 FB FIX CBY201209UBP 190 0805(ROHS) L22 FB5 L4 L8 FB22 FB38 L55
6 E1111-016001R2 FB FIX CHIP CBY321611UBP 190 1206(ROHS) L35 L37 L82 FB36
7 E1112-001007R0 COIL FIX LBS7045-470MT 47uH 0.75A (RoHS) L56 L58
8 E1301-002001R1 CAP EC V CD11X-BP T05 100M 16DC 4×7 (RoHS)
CE5 CE22 CE23 CE24 CE25 CE26
CE27 CE28 CE38 CE40 CE43 CE47
CE50 CE51 CE52 CE53 CE54 CE55
CE56 CE57 CE58 CE60 CE62 CE63
CE64 CE65 CE66 CE67 CE71 CE72
CE74 CE75 CE83 CE87 C98 CE136
9 E1301-002003R1 CAP EC V CD11X-BP T05 330M 16DC 5×7 (RoHS) CE86 CE108 CE111 CE115 CE119
10 E1301-002004R1 CAP EC V CD11X-BP T05 470M 16DC 5×7 (RoHS)
CE21 CE36 CE37 CE41 CE70 CE122
CE126 CE128 CE135
11 E1301-002005R1 CAP EC V CD11X-BP T05 101M 16DC 6.3×7 (RoHS)
CE8 CE10 CE11 CE12 CE14 CE15
CE17 CE18 CE19 CE33 CE34 CE35
CE76 CE88 CE100 CE123 CE127
12 E1301-002008R1 CAP EC V CD11X-BP T05 471M 16DC 8×12 (RoHS)
CE1 CE3 CE4 CE73 CE77 CE85 CE89
CE92 CE97 CE114 CE134
13 E1301-003003R1 CAP EC V CD11X-BP T05 220M 25DC 5×7 (RoHS) CE81
14 E1301-009001R1 CAP EC V CD11X-BP T05 221M 25DC 8×9 (RoHS) CE20
15 E1301-012015R1 CAP EC V CD11-BP T05 221M 16DC 6×12 (RoHS)
CE2 CE9 CE13 CE16 CE29 CE30
CE32 CE42 CE44 CE45 CE46 CE68
CE69 CE78 CE84 CE90 CE95 CE101
16 E1301-013010R1 CAP EC V CD11-BP T05 102M 25DC 12×20 (RoHS) CE82 CE91
17 E1301-014012R1 CAP EC V CD11-BP T05 102M 35DC 13x20 (ROHS) CE61
18 E1301-020004R1 CAP EC V CD11 T05 101M 16DC 5×7(RoHS) CE93
19 E1321-230037R1 CAP POLYESTER FILM CL11 224J 100VDC (RoHS) CB90 CB91
20 E1326-001006R2 CAP CHIP CC41-CGNT NPO T06 5R0J 50DC 0603 (RoHS) C50 C53 C57 C58 C59
21 E1326-001011R2 CAP CHIP CC41-CGNT NPO T06 100J 50DC 0603 (RoHS) C185
22 E1326-001013R2 CAP CHIP CC41-CGNT NPO T06 150J 50DC 0603 (RoHS) C68 C74 C80 C87 C89 C93 C94 C95
DRIVE PCB ASSEMBLY (W/O AV YPRPB) (RoHS)
FOR REFERENCE ONLY
The components shown in the remaining pages served as a reference only. It is not meant for ordering of
componesnts for servicing purposes.Do not quote any components from these lists.
-57-
