Item Part No. Description Location
23 E1326-001014R2 CAP CHIP CC41-CGNT NPO T06 180J 50DC 0603 (RoHS) C2 C1 C46 C47
24 E1326-001018R2 CAP CHIP CC41-CGNT NPO T06 270J 50DC 0603 (RoHS) C143
25 E1326-001029R2 CAP CHIP CC41-CGNT NPO T06 151J 50DC 0603 (RoHS) C105 C103
26 E1326-001032R2 CAP CHIP CC41-CGNT NPO T06 221J 50DC 0603 (RoHS) C99 C101
27 E1326-001035R2 CAP CHIP CC41-CGNT NPO T06 331J 50DC 0603 (RoHS)
C65 C66 C71 C72 C77 C78 C83 C84
C149 C151 C145 C146
28 E1326-001040R2 CAP CHIP CC41-CGNT NPO T06 821J 50DC 0603 (RoHS) C106 C104
29 E1326-001057R2 CAP CER CHIP CC41-CGNT NPO 1R8J 50DC 0603 C91
30 E1326-003015R2 CAP CER CHIP CC41-BNT X7R T06 102K 50DC 0603 (RoHS)
C36 C37 C38 C39 C40 C41 C42 C43
C44
31 E1326-003020R2 CAP CER CHIP CC41-BNT X7R T06 222K 50DC 0603 (RoHS) C100 C102
32 E1326-003023R1 CAP CER CHIP CC41-BNB X7R T06 332K 50DC 0603 (RoHS) C3 C6 C8 C9 C10 C34 C35
33 E1326-003029R2 CAP CER CHIP CC41-BNT X7R T06 103K 50DC 0603 (RoHS)
C5 C23 C48 C60 C61 C107 C109 C111
C112 C117 C118 C119 C120 C49 C52
C54 C67 C73 C79 C86 C88 C90 C92
C141 C142 C144
34 E1326-003039R2 CAP CER CHIP CC41-BNT X7R 473K 50DC 0603 (RoHS) C63 C64 C69 C70 C75 C76 C81 C82
35 E1326-003051R2 CAP CER CHIP CC41-BNT X7R 472K 50DC 0603 (RoHS) C51 C62 C85
36 E1326-055029R2 CAP CER CHIP 0603F 104M500NB 104M 50D 0603 (ROHS)
CB1
CB2
C4
CB5
CB6
CB7
CB8
CB9
CB10 CB11 CB12 C12 CB13 CB14
CB15 CB16 CB17 CB18 CB19 CB20
CB21 CB22 C22 CB23 CB24 CB25
CB26 CB27 CB28 CB29 CB30 CB31
CB32 CB33 CB34 CB36 CB38 CB40
CB41 CB42 CB43 CB45 C45 CB46
CB47 CB48 CB49 CB50 CB51 CB52
CB53 CB54 CB55 CB56 CB57 CB58
CB59 CB60 CB61 CB62 CB63 CB64
CB65 CB66 CB67 CB68 CB69 CB70
CB71 CB72 CB73 CB74 CB75 CB76
CB77 CB78 CB79 CB80 CB81 CB82
CB83 CB84 CB85 CB86 CB87 CB88
CB89 CB93 CB94 CB95 CB96 CB98
CB99 CB100 CB101 CB107 CB109
CB112 CB113 C114
37 E1326-064002R2 CAP CER CHIP CC41-0805E106Z T08 106Z 10DC 0805 (ROHS) C11 C20 C21 C24
38 E1326-105031R2 CAP CER CHIP CC41-FNT Y5V 105M 25DC 0603(ROHS)
C15 C17 C18 C32 C33 CB35 CB37
CB44 CB92 C96 C97 C148 C150
39 E1326-106001R2 CAP CER CHIP 475Z 6.3DC 0603 (ROHS)
C13 C14 C16 C19 C25 C26 C27 C28
C29 C30 C31
40 E1503-321109R1 RES MOF H 2W S 430J T52 (RoHS) R5 R7
41 E1505-011003R2 RES CHIP RC-03KTP T06 1/10W 100J 0603 (RoHS)
R263 R301 R321 R329 R338 R358
R395
42 E1505-011004R2 RES CHIP RC-03KTP T06 1/10W 101J 0603 (RoHS)
R14 R18 R22 R40 R42 R101 R103
R169 R176 R177 R179 R212
43 E1505-011005R2 RES CHIP RC-03KTP T06 1/10W 102J 0603 (RoHS)
R1
R45
R64
R88
R90
R121
R171
R180
R181 R191 R259 R260 R340 R364
R199 R207
FOR REFERENCE ONLY
DRIVE PCB ASSEMBLY (W/O AV YPRPB) (RoHS)
The components shown in the remaining pages served as a reference only. It is not meant for ordering of
componesnts for servicing purposes.Do not quote any components from these lists.
Parts List (For Reference Only)
-58-
