Item Part No. Description Location
44 E1505-011006R2 RES CHIP RC-03KTP T06 1/10W 103J 0603 (RoHS)
R4 R11 R34 R35 R51 R53 R54 R99 R100
R114 R115 R162 R172 R173 R178 R183
R186 R194 R208 R213 R214 R217 R218
R220 R221 R226 R227 R230 R231 R272
R273 R304 R327 R334 R335 R339 R356
R363 R371 R379 R381 R382 R242 R135
R287 R211 R206 R406
45 E1505-011007R2 RES CHIP RC-03KTP T06 1/10W 104J 0603 (RoHS)
R148 R150 R153 R156 R157 R158
R159 R161 R184 R189 R203 R140
R413
46 E1505-011008R2 RES CHIP RC-03KBP T06 1/10W 105J 0603 (RoHS) R82 R25
47 E1505-011013R2 RES CHIP RC-03KTP T06 1/10W 111J 0603 (RoHS) R336 R243
48 E1505-011042R2 RES CHIP RC-03KBP T06 1/10W 153J 0603 (RoHS) R160 R170
49 E1505-011057R2 RES CHIP RC-03KTP T06 1/10W 180J 0603 (RoHS) R216 R222 R223
50 E1505-011059R2 RES CHIP RC-03KTP T06 1/10W 182J 0603 (RoHS) R258
51 E1505-011068R2 RES CHIP RC-03KBP T06 1/10W 202J 0603 (RoHS) R110 R113 R204 R380 R414
52 E1505-011069R2 RES CHIP RC-03KTP T06 1/10W 203J 0603 (RoHS) R9 R6
53 E1505-011075R2 RES CHIP RC-03KTP T06 1/10W 220J 0603 (RoHS) R58 R59
54 E1505-011076R2 RES CHIP RC-03KTP T06 1/10W 221J 0603 (RoHS) R262
55 E1505-011078R2 RES CHIP RC-03KTP T06 1/10W 223J 0603 (RoHS) R182 R190
56 E1505-011101R2 RES CHIP RC-03KTP T06 1/10W 301J 0603 (RoHS) R13 R17 R21
57 E1505-011108R2 RES CHIP RC-03KTP T06 1/10W 330J 0603 (RoHS)
R80 R267 R376 R377 R164 R166 R167 R168
R188 R196 R330 R240
58 E1505-011110R2 RES CHIP RC-03KTP T06 1/10W 332J 0603 (RoHS) R239 R298 R328 R347
59 E1505-011111R2 RES CHIP RC-03KTP T06 1/10W 333J 0603 (RoHS) R361 R322
60 E1505-011127R2 RES CHIP RC-03KTP T06 1/10W 393J 0603 (RoHS) R141 R142
61 E1505-011140R2 RES CHIP RC-03KTP T06 1/10W 470J 0603 (RoHS) R16 R20 R24
62 E1505-011141R2 RES CHIP RC-03KTP T06 1/10W 471J 0603 (RoHS) R397
63 E1505-011142R2 RES CHIP RC-03KTP T06 1/10W 472J 0603 (RoHS)
R2 R37 R38 R41 R46 R55 R72 R87
R197 R210 R215 R383
64 E1505-011143R2 RES CHIP RC-03KTP T06 1/10W 473J 0603 (RoHS)
R8 R43 R44 R67 R68 R144 R146 R147
R149 R192 R326 R370
65 E1505-011148R2 RES CHIP RC-03KTP T06 1/10W 510J 0603 (RoHS) R47 R48 R49 R50 R165 R175
66 E1505-011149R2 RES CHIP RC-03KTP T06 1/10W 511J 0603 (RoHS) R15 R19 R23 R109 R112
67 E1505-011150R2 RES CHIP RC-03KTP T06 1/10W 512J 0603 (RoHS) R163 R174 R187 R195
68 E1505-011151R2 RES CHIP RC-03KTP T06 1/10W 513J 0603 (RoHS) R154 R155
Parts List (For Reference Only)
The components shown in the remaining pages served as a reference only. It is not meant for ordering of
componesnts for servicing purposes.Do not quote any components from these lists.
DRIVE PCB ASSEMBLY (W/O AV YPRPB) (RoHS)
FOR REFERENCE ONLY
-59-
