Item Part No. Description Location
69 E1505-011156R2 RES CHIP RC-03KTP T06 1/10W 560J 0603 (RoHS) R219 R224 R225
70 E1505-011172R2 RES CHIP RC-03KTP T06 1/10W 680J 0603 (RoHS)
R92 R97 R106 R120 R124 R128 R134
R136 R139
71 E1505-011180R2 RES CHIP RC-03KTP T06 1/10W 750J 0603 (RoHS)
R93 R98 R107 R233 R237 R248 R249
R252 R253 R257 R264 R271 R302
R305 R306 R323 R324 R325
72 E1505-011190R2 RES CHIP RC-03KTP T06 1/10W 822J 0603 (RoHS) R138
73 E1505-011202R2 RES CHIP RC-03KTP T06 1/10W 000 0603 (RoHS)
R26 R28 R30 R32 R39 R52 R57 L61 R61
R71 R73 R74 L74 R76 R77 R78 R79 R84
R85 R86 R89 R91 R95 R96 R102 R104
74 E1505-025003R1 RES CHIP RC-05KJT 1/8W 100J 0805 (RoHS) R143 R145
75 E1505-025202R1 RES CHIP RC-05KJT 1/8W 000 0805 (RoHS) FB9
76 E1510-001108R2 RES CHIP TFN RCML08WTP 1/16W 330J 0603×4 (RoHS) RN9 RN10 RN11 RN12
77 E2111-001015R1 TR PNP CHIP TC3906 SOT-23 TP (RoHS) Q9 Q22
78 E2112-001016R1 TR NPN CHIP TC3904 SOT-23 TP (RoHS)
Q1 Q2 Q3 Q5 Q6 Q7 Q8 Q10 Q11 Q12
Q13 Q14 Q15 Q17 Q18 Q19 Q21 Q23
Q24 Q25 Q29 Q32 Q33 Q34 Q35
79 E2115-001006R1 TR AP9435GM SINGLE P-CHANNEL MOSFET SO-8(RoHS) U22
80 E2115-001022R0 SSS2N7002E N-CHANNEL ENHANCEMENT MODE MOSFET SOT23 (RoHS) QF3 QF4 QF5
81 E2301-001091R0
IC TFA9843J 2-CHANNEL AUDIO AMPLIFIER(SE:1W TO 20W RO BTL:4W TO 40W
DBS9P
U23
82 E2351-001176R0 IC AIC1084CE 5A LOW DROPOUT POSITIVE REGULATOR TO-252 (RoHS) U3 U5 U4 U6 U7 U8
83 E2351-001206R0 IC AF24BC02-SI(2K) 2-wire Serial EEPROM 8-pin SOIC (RoHS) U16 U17
84 E2351-001210R0 IC AZ1117H-1.8 (RoHS) U13
85 E2351-001222R0 IC MT8201 ADC+DECODER+SCALING+MCU LQFP-256 (RoHS) U9
86 E2351-001223R0 IC MT8293 HDMI PANELLINK RECEIVER LQFP128 (RoHS) U15
87 E2351-001225R0 IC WM8776 LQFP48 (RoHS) U18
88 E2351-001227R0 IC AT24C04N-10SI-2.7 4K(256X8) SERIAL EEPROM 8S1 (RoHS) U14
89 E2351-001237R0 IC AZ4558CM-E1 DUAL OPERATIONAL AMPLIFIER SOIC-8 (RoHS) U19 U20
91 E2354-001058R0 IC ES29LV800EB-70TG 8M FLASH MEMORY TSOP48 (RoHS) U10
92 E2354-001064R0 IC SDRAM M12L64164A-5TG TSOP-54(RoHS) U12
Parts List (For Reference Only)
FOR REFERENCE ONLY
DRIVE PCB ASSEMBLY (W/O AV YPRPB) (RoHS)
The components shown in the remaining pages served as a reference only. It is not meant for ordering of
componesnts for servicing purposes.Do not quote any components from these lists.
-60-
