Item Part No. Description Location
93 E2501-003021R1 DIODE SILICON H 1N5404 T52 DO-201AD BP (RoHS) D92 D93
94 E2502-001009R0 DIODE CHIP LL4148 (RoHS)
D15 D16 D26 D27 D28 D29 D66 D11
D1 D88 D89 D90
95 E2502-001014R0 MULTILAYER VARISTOR CHIP TYPE EZJZ1V270GA 0603 ESD
D14 D17 D18 D19 D20 D21 D22 D23
D24 D25 D30 D31 D32 D33 D34 D35
D36 D37 D38 D39 D40 D41 D42 D44
D45 D46 D48 D49 D50 D51 D52 D53
D54 D55 D56 D57 D58 D60 D61 D62
D63 D64 D65
96 E3101-001002R1 PLUG PH-3A PIN HEADER (180°) 2.0mm 3P (RoHS) J12
97 E3101-001003R1 PLUG PH-4A PIN HEADER (180°) 2.0mm 4P (RoHS) J4 J3
98 E3101-001005R1 PLUG PH-6A PIN HEADER (180°) 2.0mm 6P (RoHS) J10
99 E3101-001008R1 PLUG PH-6A PIN HEADER (180°) 2.0mm 9P (RoHS) J11
100 E3101-002001R1 PLUG TJC3-11A PIN HEADER (180°) 2.5mm 2P (RoHS) J2
101 E3101-002010R1 PLUG TJC3-11A PIN HEADER (180°) 2.5mm 11P (RoHS) J1
102 E3101-015005R1 SOCKET PIN HEADER (180°) 2.0mm 2×15P (RoHS) J5
103 E3201-001090R1 SOCKET PIN SCART CS-2104 21P (RoHS) P9
104 E3201-001095R1 JACK PIN AV4-13W-070 W/R W/R 4P (RoHS) P6
105 E3201-001125R1 SPEAKER JACK CK3-3.5-720 7P (RoHS) J13 J14
106 E3201-001126R2 D-sub 1152-015-201-000 3.08mm Footprint 15P (90°) (RoHS) P2
107 E3201-001137R1 JACK PIN AV6-11WD-550 G/B/R Y/W/R 6P (RoHS) P8
108 E3201-001138R1 JACK PIN AV-S+02B 4P/1P(RoHS) P5
109 E3202-001047R1 JACK HDMI RIGHT ANGLE HEADER ASSRMBLY E11001-04 (RoHS) P1
110 E3702-002143R3 MTK32H81 DRIVE PCB 293mmX142mm (RoHS)
111 E4301-001070R0 OSCILLATOR X' TAL HC-49US 27.000MHz (RoHS) Y1 Y2
112 E5401-001031R0 TUNER JS-6H2/121A25 PAL BG/DK/I SECAM L/L' XUGUANG(RoHS) TU1
113 M4601-32B614100R HEAT SINK AL THK=2.0MM (RoHS)
114 M4601-32B622000R HEAT SINK AL (RoHS)
115 M8004-300603413R SELF-TAPPING SCREW WITH BINDING HEAD BST3X6HZn (RoHS) HEAT SINK -1
116 M8007-300801313R
SELF-TAPING SCREW FOR METAL WITH
FLAT HEAD KTB3.0×8B-HZn (RoHS)
HEAT SINK -2
DRIVE PCB ASSEMBLY (W/O AV YPRPB) (RoHS)
Parts List (For Reference Only)
FOR REFERENCE ONLY
The components shown in the remaining pages served as a reference only. It is not meant for ordering of
componesnts for servicing purposes.Do not quote any components from these lists.
-61-
To Next Page
