Telepass SAT| Operating instruction v. 1.11 OCT 2020|© 2016-2020 Telepass 29
EN
CARE FOR THE DEVICE
Cleaning
Use a soft cloth, dampened with a
multipurpose detergent to clean the unit.
Device return
Do not discard the device with unsorted waste.
Return the device to the provider in the following
cases:
l device malfunction
l end of use or service contract termination
TECHNICAL SPECIFICATIONS
Dimensions
139 x 96 x 30 mm (support bracket not
included)
Weight
320 g (support bracket not included)
External material Plastic (ABS)
Protection grade IP 41
Working temperature
-30 °C to +80 °C
Power from vehicle 10–30 V dc
Internal battery 3.6 V/2200 mAh Li-ion rechargeable
battery
Internal battery life
Uninterrupted operation: up to 3 hours.
DSRC only: up to 60 days.
Radio-frequency band
DSRC: 5725–5875 MHz, GSM: dual
band 900/1800 MHz.
DSRC antenna features
Circular polarization patch antenna
Output power
DSRC: under -21 dBm, EGSM900:
class 4 (+33 dBm ±2 dB),
GSM1800: class 1 (+30 dBm ±2 dB)
GNSS standards GPS, Galileo, GLONASS
SBAS EGNOS (Europe)
