CA824 Installation manual 23
Installation for input and output expander modules in plastic box
The producer has provided additional positions for extra modules and devices for the plastic box (fig.
15a). Up to four expanders for inputs and/or outputs can be fitted together with control panel and
accumulator, as it is shown on fig. 15a.
Fig. 15a Installation for Input and Output expander modules
