22 CA824 Installation manual
Installation box for input and output expander modules
The terminals are installed in the box (fig. 15) by the producer. A maximum of two input and/or output
expanders can be installed in one box, as shown in Fig. 15.
The self-protection key is installed and configured by the producer.
Technical specifications of the expander installation box
Box dimensions - 128 x 103 x 54 mm
