CA824 Installation manual 7
LEAVING PROGRAMMING MODE
To exit programming mode press CLR several times until the display shows 9) Engineer out good-bye?,
and then confirm by pressing ENT.
If the system siren is triggered, introduce a valid user code, select from the list the area which caused
the alarm and then press the DISARM button to stop it. It would be sufficient to merely introduce this
code to stop the siren by introducing a code, where this is permitted.
NEW PnP HARDWARE IDENTIFICATION PROCEDURE
Every module from the CA824 system set has a singular number, recorded during the production pro-
cess. This number consists of two parts – batch number and device type, and is used to carry out the
new hardware identification procedure or to load factory settings. After this procedure is completed,
each identified device is assigned a number, singular to the system, and used to indicate the location of
the module within the list of devices, which comprise the security system. The module uses it to partici-
pate in the exchange along the bus.
The PnP procedure is used to include the new modules within the logical structure of the system, which
are connected to the communication network.
Input? Zone? Type Area Zone parameters
1 1 Entry/Exit 1 AutoZoneShutdown, Chime, Audible
2 2 Follow 1 AutoZoneShutdown, Stay, Audible
3 3 Instant 1 AutoZoneShutdown, Stay, Force, Audible
4 4 Instant 1 AutoZoneShutdown, Stay, Force, Audible
5 5 Instant 1 AutoZoneShutdown, Stay, Force, Audible
6 6 Instant 1 AutoZoneShutdown, Stay, Force, Audible
7 7 Panic 1
8 8 Tamper 1
Table 2 System factory configurations for inputs
Table 3 System factory configurations for outputs
Output ? PGM? Parameters of PGM
1 1 ARM area 1
2 2 Alarm, Tamper
3 3 Technical trouble
4 4 Siren
