CA824 Installation manual 9
Fig. 2 CA824 control panel box
CA824 control panel box
TAMPER button
Front lid
Bottom
CA 864 control panel
Transmitter support strap
Pull lid forward 3
Lift lid up
2
Undo screws
1
4
Remove earthing cable
+
B
A
T
T
-
B
L
A
C
K
R
E
D
F AUX
2A
F PGM
2A
RED
YELLGRN
BLACK
BUS CONNECTION
LED COM MUNICATOR
SERVICE
BUS CONNECTOR
RESET
B1 A 1 AB
CA 824
IN8GNDIN7IN6GNDIN5IN4GNDIN3IN2GNDIN1AC + AUX - + PGM OUT1 OUT2 OUT3BELL
F BATT
2A
1
6
3
5
1
4
12V / 7 Ah
battery
F - 0,63 A
Mains
transformer
50 / 60 Hz
15-25 V / 50VA
1
2
1 - Support opening
2 - CA 824 control panel
3 - Mains power supply terminal
4 - Signal cable openings
5 - Mains power supply cable
opening
6 - TAMPER button for box
self-protection
