6 CA824 Alarm System User Manual
Symbol Description
Click Single short beep indicating button pressing
Confirm
One long and three short beeps indicating the system
confirmation to executed operation (arming, disarming,
settings change, etc.)
Reject Single long beep indicating incorrectly executed operation
Entrance
time
Continuous sound indicating intrusion into the entrance
zones
Exit time
Short beeps indicating the system is armed and the user is
required to leave the zone. Ten seconds before the exit time
is over beeps frequency is increased.
Trouble
Two short beeps indicating problem with the system (battery
low, no supply voltage, etc.)
Chime
Chime-like sound beeps indicating intrusion into a zone with
a “Chime“ option activated (usually the entrance door)
Alarm
LED Indication
LED Indication description
Mains Power Supply LED (Green). Lit at 220V mains power supply.
Trouble LED (Yellow). Lit at system trouble.
The trouble type is displayed in the troubles list.
Alarm LED (Red). Lit at system alarm status or alarm memory.
Fire alarm LED (Red). Lit at system fire alarm status or fire alarm memory
Service LED (Red). Lit at system programming by service technician.
LCD Display
The keyboard is equipped with a 2-row 16-colomn matrix LCD providing different
system trouble and event memory alpha-numerical messages.
