Televes Ellipse Mix User Manual

4
5
6
Prepare the coaxial cable as illustrated in the
diagram before terminating the coax cable
(installing the F-connector).
When using the provided weather boot and
twist-on connector on an unterminated
coaxial cable, slide the weather boot
H
onto
the coaxial cable and properly terminate and t
the twist-on connector
G
to the coaxial cable.
Pass the cable with the connector through
the 1st slot in the lower reector.
Note: In place of the provided twist-on F-connector
a crimp-on F-connector may be used in its place if
available and the installer is familiar with this type of
connector and has the tools to properly crimp them.
Screw connector
G
onto the threaded male
input connection of the dipole assembly
F
and tighten with the 216120 accessory but do
not overtighten, then slide the weather boot
H
over the connector as far as it will go.
Insert the Dipole assembly
F
into the antenna
orange junction box, sliding it through the
guide slot to the point where you will hear an
audible “click” indicating the dipole is latched
into place and fully seated in the main body of
the antenna.
Visually check the dipole once installed to make
sure there are no gaps and that it did fully seat.
Place the second
D
UHF reector in the self-
locking clamp by inserting the open end of
the reector without the grey plastic cap on it
and with the black plastic locking mechanism
in an upward position (unlocked).
Once the reector is fully seated in the clamp
(all the way to the bottom of the slot), lock
them in place by rmly pressing down on the
black plastic latches.
An audible “click” will be heard when the
reector is securely locked in place.
7
Place the
E
VHF reectors (two pieces, one
top and one bottom) in the self-locking clamp
by inserting the open end of the reector
without the grey plastic cap on it and with the
black plastic locking mechanism in an upward
position (unlocked).
Once the reectors are fully seated in the
clamp (all the way to the bottom of the slot),
lock them in place by rmly pressing down on
the black plastic latches.
An audible “click” will be heard when the
reectors are securely locked in place.
G H
9/32”
(7mm)
1/8”
(3mm)
G
H
D
D
F
E x2
F
G
H
CLICK!
CLICK!
E
E
D
D
CLICK!
