Pg 6
1.8 Revision History
Revision
Date
Changes
1.8 07.07.2022 Initial version
Table 2: Documentation change log
2 Product Description
2.1 Overview
The pictures below show the mechanical design of the LT910-WW Terminal along with the
positions of the different connectors and mounting holes. The LT910-WW Terminal case is made
of durable PC/ABS plastics.
Figure 1: Connectors on rear side of the Terminal
