5. ELECTRICAL SPECIFICATIONS
Absolute Maximum Ratings – Not Operational
Warning: A deviation from the value ranges listed below may harm
the LM940 module.
Symbol
Parameter
Min
Max
Unit
VBATT
Battery supply voltage on
pin VBATT
-0.5
4
[V]
Table 19: Battery Supply Voltage on Pin VBATT
Recommended Operating Conditions
Symbol
Parameter
Min
Typ
Max
Unit
T
amb
Ambient
temperature
-40
25
85
[°C]
VBATT
Battery supply
voltage on pin
VBATT
3.1
3.3
3.6
[V]
I
VBATT +
Peak current to be
used to dimension
decoupling
capacitors on pin
VBATT
-
80
2500
[mA]
I
VBATT_PA
Table 20: Recommended Operating Conditions
