8. MECHANICAL DESIGN
General
The LM940 module was designed to be compliant with a standard lead-free SMT process.
Moreover, it is compatible with the Mini PCIe card 52-pin card edge-type connector.
Finishing and Dimensions
N/A
Drawing
Figure 20, shows the mechanical dimensions of the LM940 module.
Figure 20: Mechanical Design Drawing
