12. REFERENCE TABLE OF RF BANDS CHARACTERISTICS
Mode
Freq. Tx (MHz)
Freq. Rx (MHz)
Channels
Tx-Rx Offset
WCDMA 2100 – B1
1920 ~ 1980
2110 ~ 2170
Tx: 9612 ~ 9888
Rx: 10562 ~ 10838
190 MHz
WCDMA 1900 – B2
1850 ~ 1910
1930 ~ 1990
Tx: 9262 ~ 9538
Rx: 9662 ~ 9938
80 MHz
WCDMA AWS – B4
1710 ~ 1755
2110 ~ 2155
Tx: 1312 ~ 1513
Rx: 1537 ~ 1738
400 MHz
WCDMA 850 – B5
824 ~ 849
869 ~ 894
Tx: 4132 ~ 4233
Rx: 4357 ~ 4458
45 MHz
WCDMA 900 – B8
880 ~ 915
925 ~ 960
Tx: 2712 ~ 2863
Rx: 2937 ~ 3088
45 MHz
LTE 2100 – B1
1920 ~ 1980
2110 ~ 2170
Tx: 18000 ~ 18599
Rx: 0 ~ 599
190 MHz
LTE 1900 – B2
1850 ~ 1910
1930 ~ 1990
Tx: 18600 ~ 19199
Rx: 600 ~ 1199
80 MHz
LTE 1800+ – B3
1710 ~ 1785
1805 ~ 1880
Tx: 19200 ~ 19949
Rx: 1200 ~ 1949
95 MHz
LTE AWS-1 – B4
1710 ~ 1755
2110 ~ 2155
Tx: 19950 ~ 20399
Rx: 1950 ~ 2399
400 MHz
LTE 850 – B5
824 ~ 849
869 ~ 894
Tx: 20400 ~ 20649
Rx: 2400 ~ 2649
45 MHz
LTE 2600 – B7
2500 ~ 2570
2620 ~ 2690
Tx: 20750 ~ 21449
Rx: 2750 ~ 3449
120 MHz
LTE 900 – B8
880 ~ 915
925 ~ 960
Tx: 21450 ~ 21799
Rx: 3450 ~ 3799
45 MHz
LTE 700a – B12
699 ~ 716
729 ~ 746
Tx: 23010 ~ 23179
Rx: 5010 ~ 5179
30 MHz
LTE 700c – B13
777 ~ 787
746 ~ 756
Tx: 23180 ~ 23279
Rx: 5180 ~ 5279
-31 MHz
LTE 700b – B17
704 ~ 716
734 ~ 746
Tx: 23730 ~ 23849
Rx: 5730 ~ 5849
30 MHz
LTE 800 – B20
832 ~ 862
791 ~ 821
Tx: 24150 ~ 24449
Rx: 6150 ~ 6449
-41 MHz
LTE 1900+ – B25
1850 ~ 1915
1930 ~ 1995
Tx: 26040 ~ 26689
Rx: 8040 ~ 8689
80 MHz
LTE 850+ – B26
814 ~ 849
859 ~ 894
Tx: 26690 ~ 27039
Rx: 8690 ~ 9039
45 MHz
LTE 700 APT – B28
703 ~ 748
758 ~ 803
Tx: 27210 ~ 27659
Rx: 9210 ~ 9659
55 MHz
