Mode
Freq. Tx (MHz)
Freq. Rx (MHz)
Channels
Tx-Rx Offset
LTE 700 d – B29
Downlink only
717 ~ 728
Rx: 9660 ~ 9769
–
LTE 2300 WCS – B30
Downlink only
2350 ~ 2360
Rx: 9770 ~ 9869
–
LTE AWS-3 – B66
1710 ~ 1780
2110 ~ 2200
Tx: 131972 ~ 132671
Rx: 66436 ~ 67335
400 MHz
LTE TDD 2600 – B38
2570 ~ 2620
2570 ~ 2620
Tx: 37750 ~ 38249
Rx: 37750 ~ 38249
0 MHz
LTE TDD 2300 – B40
2300 ~ 2400
2300 ~ 2400
Tx: 38650 ~ 39649
Rx: 38650 ~ 39649
0 MHz
LTE TDD 2500 – B41
2496 ~ 2690
2496 ~ 2690
Tx: 39650 ~ 41589
Rx: 39650 ~ 41589
0 MHz
Table 41: RF Bands Characteristics
Note: The channel numbers that designate carrier frequencies so
close to the operating band edges that the carrier extends beyond the
operating band edge shall not be used. This implies that the first 7,
15, 25, 50, 75 and 100 channel numbers at the lower operating band
edge and the last 6, 14, 24, 49, 74 and 99 channel numbers at the
upper operating band edge shall not be used for channel bandwidths
of 1.4, 3, 5, 10, 15 and 20 MHz respectively.
NOTE – For more information on bandwidth support, refer to 3GPP
TS 36.521-1 V15.0.0, Table 5.4.2.1-1.
