Telrad CPE8000 - Getting Started with the CPE

Page 4
1.
Overview
The ODU is a high performance 4G LTE outdoor CPE product designed
to enable quick LTE fixed data service deployment to the remote
customers. It provides high data throughput and networking features to
end users who need both bandwidth and quality service in the remote
area.
1.1.
User Interface Specification
Model
Description & User Interface
ODU
- Panel antenna:
B3_7 14dBi, B20 7dBi, B38_40_41 13dBi, B42_43 15dBi
- 1 RJ45 10/100M LAN Port
- PWR, RUN, LAN, SIM, LTE(1-5) LEDs
- 48 VDC PoE supply, ODU Power <10 Watts
- Dimensions: 203 mm (L) × 203 mm (W) × 76.5 mm (D)
- Weight: < 2 Kg
1.2.
LTE Interface Specification
Frequency Bands Band 3_7 / 20 / 38_40_41 / 42_43
Radio Access 3GPP LTE Release9
Operation Mode TDD, 2RX, 1TXD, DLMIMO
Output Power Up to 23 dBm at antenna port
Throughput Category 4
SIM Support SIM card slot
2.
GettingStarted
2.1.
Packing list and CPE Unit
