Teltonika RUT951 User Manual

Respond to one ID in range [1;255] or any
Allow access through WAN
Allow Remote Access
ID range
MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS
TCP Slave functionality
Custom registers
3 x LAN ports, 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
1 x WAN port (can be configured to LAN) 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIXWAN
LAN
ETHERNET
MODBUS TCP SLAVE
4
Multiple clients and server can be running simultaneously, 12 encryption methods
DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC,
AES-192-CBC, AES-256-CBC
01, 02, 03, 04, 05, 06, 15, 16
8 bit: INT, UINT; 16 bit: INT, UINT (MSB or LSB first); 32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB,
BADC)
OpenVPN Encryption
VPN
OpenVPN
Firmware update from server, automatic notification
FOTA
HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log
MONITORING & MANAGEMENT
WEB UI
MODBUS TCP MASTER
IKEv1, IKEv2, supports up to 4 x VPN IPsec tunnels (instances), with 5 encryption methods (DES, 3DES, AES128, AES192, AES256)
GRE tunnel
IPsec
GRE
Client/Server services can run simultaneously
Proxy designed to add TLS encryption functionality to existing clients and servers without any changes in the programs' code
PPTP, L2TP
Stunnel
SSTP client instance support
ZeroTier VPN
SSTP
ZeroTier
SSH (v1, v2)
SMS status, SMS configuration, send/read SMS via HTTP POST/GET
SSH
SMS
Reboot, Status, WiFi on/off, Mobile data on/off, Output on/off
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
CALL
TR-069
MQTT Broker, MQTT publisher
SNMP (v1, v2, v3), SNMP trap
MQTT
SNMP
Management API over HTTP/HTTPS
JSON-RPC
MODBUS TCP status/control
Teltonika Remote Management System (RMS)
MODBUS
RMS
Supported functions
HTTP(S), MQTT, Azure MQTT
Allows sending commands and receiving data from MODBUS Master through MQTT broker
MODBUS DATA TO SERVER
Protocol
MQTT GATEWAY
MQTT gateway
TCP Master, DNP3 Outstation
DNP3
Supported modes
Supported data formats
Method of building scalable IPsec VPNs
DMVPN
WireGuard VPN client and server support
WireGuard
DATASHEET // RUT951
Copyright © 2022, TELTONIKA NETWORKS. Specifications and information given in this document are subject to change by TELTONIKA NETWORKS without prior notice.

Teltonika RUT951 Specifications

General

Mounting	DIN-rail
Device type	Cellular network router
Reset button	Yes
Product color	Black
Housing material	Aluminium, Plastic
Market positioning	Industrial
Ethernet LAN data rates	100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
4G standard	LTE
Data network	2G, 3G, 4G
Number of SIM cards	2
Security algorithms	AES-CCMP, HTTPS, SSH, SSL/TLS, TKIP, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Ethernet LAN (RJ-45) ports	3
Antenna type	External
Antennas quantity	4
Power source type	DC
RAM type	DDR2
RAM capacity	128 GB
Processor frequency	0.58 GHz
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	100 mm
Width	110 mm
Height	50 mm
Weight	287 g
