Teltonika RUT951 User Manual

5
IoT PLATFORMS
SYSTEM CHARACTERISTICS
FIRMWARE / CONFIGURATION
FIRMWARE CUSTOMIZATION
POWER
PHYSICAL INTERFACES (PORTS, LEDS, ANTENNAS, BUTTONS, SIM)
Can send device IP, Number of bytes send/received/ 3G connection state, Network link state, IMEI, ICCID, Model, Manufacturer,
Serial, Revision, IMSI, Sim State, PIN state, GSM signal, WCDMA RSCP WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ, CELL ID,
Operator, Operator number, Connection type, Temperature, PIN count to Azure IoT Hub server
Azure IoT Hub
Allows monitoring of: Device Model, Revision and Serial Number, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal
Strength, WAN Type and IP
Cumulocity
Allows monitoring of: Device data, Mobile data, Network info, Availability
Allows monitoring of: WAN Type, WAN IP Mobile Operator Name, Mobile Signal Strength, Mobile Network Type
Clouds of things
ThingWorx
Mediatek, MT7628, 580 MHz
CPU
128 MB, DDR2
16 MB, SPI Flash
RAM
FLASH storage
Update FW from file, check FW on server, configuration profiles, configuration backup, restore point
WEB UI
Update FW/configuration from server
Update FW/configuration for multiple devices
FOTA
RMS
Update FW without losing current configuration
Keep settings
RutOS (OpenWrt based Linux OS)
Operating system
Busybox shell, Lua, C, C++
SDK package with build environment provided
Supported languages
Development tools
4 pin industrial DC power socket
Connector
9 – 30 VDC, reverse polarity protection; surge protection >31VDC 10us max
Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt
standards
Input voltage range
PoE (passive)
< 2 W idle, < 7 W Max
Power consumption
4 x RJ45 ports, 10/100 Mbps
Ethernet
1 x Digital Input, 1 x Digital Output on 4 pin power connector (available from HW revision 1600)
1 x bi-color connection status LED, 5 x connection strength LEDs, 4 x LAN status LEDs, 1 x Power LED
I/O’s
Status LEDs
2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders, eSIM (Optional)
SIM
1 x 4 pin power connector
Power
2 x SMA for LTE, 2 x RP-SMA for WiFi antenna connectors
Antennas
Reboot/User default reset/Factory reset button
Reset
INPUT/OUTPUT
1 x Digital input, 0 - 5 V detected as logic low, 8 - 30 V detected as logic high
Input
1 x Digital open collector output, max output 30 V, 300 mA
SMS, EMAIL, RMS
Output
Events
DATASHEET // RUT951
Copyright © 2022, TELTONIKA NETWORKS. Specifications and information given in this document are subject to change by TELTONIKA NETWORKS without prior notice.

Teltonika RUT951 Specifications

General

Mounting	DIN-rail
Device type	Cellular network router
Reset button	Yes
Product color	Black
Housing material	Aluminium, Plastic
Market positioning	Industrial
Ethernet LAN data rates	100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
4G standard	LTE
Data network	2G, 3G, 4G
Number of SIM cards	2
Security algorithms	AES-CCMP, HTTPS, SSH, SSL/TLS, TKIP, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Ethernet LAN (RJ-45) ports	3
Antenna type	External
Antennas quantity	4
Power source type	DC
RAM type	DDR2
RAM capacity	128 GB
Processor frequency	0.58 GHz
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	100 mm
Width	110 mm
Height	50 mm
Weight	287 g
