TEM A07A2200S - CHAPTER 9: Rear Connections & Settings

A07A2200S
380 221 R02
A07A2200S REAR CONNECTIONS & SETTINGS
See fig. 9.d for function number
N° FUNCTION CONNECTION
1 KEYBOARD
2 DISPLAY
1 NC
2 RX ( amplifier )
3 TX ( amplifier )
4 NC
5 GND
6 NC
7 NC
8 NC
3
COM2
RS232 to power amplifier
PIN
NUMBER
( DB9 )
9 NC
4 RF MONITOR
5 BF MONITOR
1 NC
2 NC
3 NC
4 NC
5 GND
6 EXTERNAL PWD
7 EXTERNAL PWR
8 NC
6 AUX IN/OUT
PIN
NUMBER
( DB9 )
9
Field 1000W (Opt remote Zarat)
