Temco TFC36-3 - Replacement Parts; Parts List and Availability

REPLACEMENT PARTS
The following replacement parts are available from your TEMCO dealer.
Description Quantity
Part #
42" 39" 36"
1. Firescreen rod, straight 2 3T65864 3T65730 3T65648
2. Screws for screen rods 2 1A68188 1A68188 1A68188
3. Firescreen with rings 2 1T62197 1T66146 1T66146
4. Screen retainer 4 1A62222 1A62222 1A62222
5. Refractory retainer, right side 1 2B70358 2B70358 2B68316
6. Refractory retainer, left side 1 2B70358 2B70358 2B68339
7. Refractory retainer, front 1 - - 2C68372
8. Screws for refractory retainers 2 1A68188 1A68188 1A68188
9. Right side refractory 1 2D70355 2D70355 2D68337
10. Left side refractory 1 2D70355 2D70355 2D68338
11. Back refractory 1 2D70357 2D70425 2D66993
12. Bottom refractory 1 2D70354 2D70424 2D68336
13. Integral grate 1 1D70361 1D68373 1D68373
14. Grate retaining bracket 2 2B66130 2B66130 2B66130
