Page 5
Operation
On/Off
Starting Operation
When the unit is turned off, press the button. The backlight and the
system are turned on.
Bypass Operation
To activate the air conditioner outside any pre-set times, follow the instructions in
page 7.
Stopping Operation
When the unit is turned on, press the button. The system is turned off.
Room Temperature Adjustment
Normally the display will show the current room temperature (not the preset
temperature). Set the temperature of your choice by pressing the or
buttons. The preset temperature will appear.
Each push will change the temperature by 1ºC.
Temperature can set within the range 16ºC ─ 30ºC.
During Fan mode, the temperature can not be set.
Mode Selection
Press the
M O D E
button to switch operation between Cool, Fan, Dry, Heat and
Auto. The display shows which mode is selected at any one time.
Cool ─ If the room temperature is too warm, the air conditioner cools the room
until it reaches the set temperature.
Dry ─ If the atmosphere in the room is very humid or damp, use this mode to
both reduce the humidity and cool until the room is near the set temperature.
Heat ─ If the room temperature is too cool, the air conditioner warms the room
until it reaches the set temperature (reverse cycle systems only).
Auto ─ The air conditioner will automatically cool or heat the room until it reaches
the set temperature (reverse cycle systems only).
Fan ─ If the atmosphere in the room is stale, use this mode to circulate the air in
the room, without changing the overall room temperature.
Fan Speed Selection
Press
FAN
button to select Auto, High, Medium or Low speed.
Auto ─ The SAT-1 will automatically select the most suitable fan speed to
maintain set temperature.
High, Medium, Low ─ A choice of three manually selected fan speeds are
available.
Swing Activation
This function is only applicable to systems with under ceiling indoor units.
Press
button to activate the air louver sweep function, or to set the louver
at a preferred angle.
