Tempur-Pedic EASE - Quick Reference Guide; Control Box Diagram; Electronics Connection Diagram

5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
Power Cord
Power Supply
Wireless
Remote
Head Motor
Foot Motor
Control Box
ELECTRONICS OVERVIEWCONTROL BOX OVERVIEW
Input
Power Cord
If installing a split unit, see pages 10-11.
Power Cord
Multifunction
port
Head
Motor Port
Foot Motor
Port
Battery Backup Strap
