TEMPUR ERGO 2.0 - Quick Reference Guide

5
If installing a split unit, see pages 12-13.
quick reference guide
Power Cord
Input
Power Cord
Not to scale . For illustration purposes only . Read all instructions before beginning installation .
Control Box
Power Supply
connection ports
to head and foot
motors (massage
and lift). Installed
under the base.
Battery Backup Box
USB Charging Ports
USB Charger
Splitter
Underbed Lighting
