Tenda A21 User Manual

03
A21| AC2100 Dual Band Wi-Fi Range Extender
Main Features
Intelligent LED Indicator
After the bridge is completed，smart LED indicators can help you find the best
location for Wi-Fi coverage and improvethe qualityofsignal extension.
Blue：Good connection
Red：Toofarawayfromtherouter
Entertainment Adapter
Built-in Access Point Mode
If the extender is paired and connected to the Internet, you can also use the
Ethernet port to connect any wired devices, such as smart TV、multimedia
player、gameconsole, or PC.
Simply plug the networked Ethernet cable into the Ethernet port of A21, and you
can easilyconvert your wiredInternet connection into a dual-band wirelesssignal.
One-Touch Connection for Easy Setup
After pressing the WPS button of the router, press the WPS button of the
extender within 2 minutes toconnect.

Tenda A21 Specifications

General

Antenna type	Omni-directional
Output power	- mW
Bidirectional	No
Connector type	-
LED indicators	Activity, Power, WPS
Frequency range	2412 - 5250 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
WLAN data transfer rates supported	300, 1734 Mbit/s
Power consumption (typical)	11 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Quick installation guide	Yes

Weight and Dimensions

Depth	109 mm
Width	78 mm
Height	56.2 mm
