Tenda A21 User Manual

04 A21| AC2100 Dual Band Wi-Fi Range Extender
Specification
Hardware Specification
Wireless Features
Interface
LED indicator
Wireless Standards
Data Rate
Wireless Modes
Transmit Power
Wireless Security
Frequency
RSSI
Power Supply
Dimensions
Power Consumption
Button
Antenna Type
1*10/100/1000Mbps RJ45
1 * Signal LED
1 * WPS LED
1 * Power LED
IEEE802.11b,IEEE 802.11g, IEEE 802.11n, IEEE 802.11a,IEEE 802.11ac
5GHz: Up to 1734Mbps
2.4GHz: Up to 300Mbps
Repeater Mode，Access Point Mode
<20dBm
Default encryption mode: Mix WPA-PSK/WPA2-PSK
WPA algorithm: TKIP
5 GHz(11ac)
2.4 GHz
2.4 GHz
11b-1M:-97dBm
11g-54M:-76dBm
11n-20M-MCS7:-74dBm
11n-40M-MCS7:-72dBm
5 GHz:
11a-6M:-95dBm
11n-20M-MCS7:-74dBm
11n-40M-MCS7:-72dBm
11ac-80M-MCS9:-63dBm
12V1A, built-in
11W (max power consumption)
109x78x56.2mm
1 * WPS Button
1 * Reset Button
4 * External 3dBi omni-directional antenna

Tenda A21 Specifications

General

Antenna type	Omni-directional
Output power	- mW
Bidirectional	No
Connector type	-
LED indicators	Activity, Power, WPS
Frequency range	2412 - 5250 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
WLAN data transfer rates supported	300, 1734 Mbit/s
Power consumption (typical)	11 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Quick installation guide	Yes

Weight and Dimensions

Depth	109 mm
Width	78 mm
Height	56.2 mm
