Tenda AC21 User Manual

93
Configuring procedure:
Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in
to the web UI of the router.
Step 2 Choose IPv6.
Step 3 Enable the IPv6 function.
Step 4 Set the connection type to DHCPv6.
Step 5 Click Save.
---End
Parameter description
Parameter
Description
Obtain IPv6 Prefix
Delegation
When the option is selected, the LAN port of router obtains IPv6 prefix from it upstream
device.
It is recommended to keep the default setting (Selected). If the LAN port cannot obtain
the PD prefix, it is because the upstream device does not support PD prefix delivery.
Contact your ISP to solve this problem.
IPv6 network test:
Start a web browser on a phone or a computer that is connected to the router, and visit

Tenda AC21 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	6
Antenna gain level (max)	6 dBi
Cables included	LAN (RJ-45)
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	150.6 mm
Width	231.3 mm
Height	39.6 mm
