76
Configuring procedure:
Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in
to the web UI of the router.
Step 2 Choose VPN > PPTP Server.
Step 3 Enable the PPTP Server.
Step 4 Enable the MPPE Encryption, which means that the encryption digit remains the default
value “128”.
Step 5 Set the User Name and Password of the PPTP server, which are admin1 in this example.
Step 6 Click +New.
Step 7 Click Save.
---End
When completing the configurations, internet users can access the FTP server by following these
steps:
Step 1 Click the icon at the bottom right corner on the desktop, and then click Network
settings.

Table of Contents

Other manuals for Tenda AC21

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda AC21 and is the answer not in the manual?

Tenda AC21 Specifications

General IconGeneral
USB portNo
DC-in jackYes
Connectivity technologyWireless
Ethernet LAN (RJ-45) ports3
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, System, WAN, WLAN, WPS
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2033 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)1733 Mbit/s
CertificationCE/FCC/RoHS
Processor cores2
Processor frequency1000 MHz
VPN supportIPsec, L2TP, PPTP
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Transmit power20/23 dBmW
Antennas quantity6
Antenna gain level (max)6 dBi
Cables includedLAN (RJ-45)
Output current1.5 A
Output voltage12 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Security algorithmsWPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth150.6 mm
Width231.3 mm
Height39.6 mm
