Tenda F3 User Manual

59
❷ Check the Enable box.
Configure a download bandwidth rule for the IP.
❸ IP Address: Enter “150” in two rightmost boxes. If you want to specify a rule for several
devices which get IPs within an IP range, you need to enter the start IP and end IP to these two
rightmost boxes respectively.
 Upload/Download: Select Download from the pull-down menu.
 Bandwidth Range: Enter “256” in the first box and “512” in the second box. Because your
3
2
4
5
6
7
8

Tenda F3 Specifications

General

Color	white
Wi-Fi Speed	300 megabits per second
Band Technology	single
Frequency Band	2.4 ghz
Beamforming	yes
Ethernet Standard	10/100
Ethernet Switch	yes
Wireless Standard	n
Antennas	3
Firewall	none
Data Encryption	yes
Encryption Type	wpa, wpa-psk, wpa2, wpa2-psk
Security Features	wpa algorithm: aes, tkip, tkip&aes; wireless access control: mac address filtering
Ports	rj-45
LAN Ports	3
WAN Ports	1

Weight and Dimensions

Height	1.02 inches
Width	5.02 inches
