5
2. Installation
2.1 Before Connecting to the Network
Before connecting the G1005D/G1008D to the network, please
pay attention to the following instructions:
¾ Don’t put heavy articles on the Switch.
¾ Power sockets and equipments should be within 1.5 meters
of the Switch.
¾ Check power adapter to confirm the safe connection.
¾ Make sure there’s adequate space for proper heat
dissipation and adequate ventilation around the Switch.
2.2 Connecting to End Nodes
Use standard Ethernet cable to connect the Switch to end nodes
as described below. Switch ports will automatically adjust to the
characteristics (MDI/MDIX, speed, duplex) of the device to which
is connected.
Switch connecting to an end node
