Please refer to the LED Indicator Specifications. The Link/Act LEDs for
each port lights green when the link is available.
3. Product Specification
Standards
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100 Base-TX Fast
Ethernet
Protocol CSMA/CD
Topology Star
Network Cables
10 Base -T: Cat.3 UTP or above
100 Base -TX: Cat.5 UTP /STP
Speed 10/100Mbps
Transmission Method Fast store-and-forward
MAC Address Table 2K(S105)/1K(S108)
Packet Filtering/
Forwarding Rate
14880pps(10Mbps)per port
148800pps(100Mbps)per port
MAC Address Learning Self-learning, auto-aging.
Backplane Bandwidth 1Gbps(S105)/ 1.6Gbps(S108)
Power External universal power supply
DC INPUT DC 5V 600mA
Power Consumption 2.7W(S105)/4.2W(S108)
Operating Temperature 0℃-40℃
Storage Temperature -40℃-70℃
Working Humidity 10%～90% RH (no condensing)
Storage Humidity 5%～95% RH (no condensing)
