Network Mode：Select one mode from the following. The default is 11b/g/n mode.
11b mode： Allow the wireless client to connect with the device in 11b mode at the maximum
speed of 11Mbps.
11g mode： Allow the 11g/11n-compliant client device to connect with the AP at the maximum
speed of 54Mbps.
11b/g mode: Allow the 11b/g-compliant client device to connect with the AP with auto-
negotiation speed, and 11n wireless client to connect the device with 11g
speed.
11b/g/n mode: Allow 11b/g/n-compliant client device to connect with the AP with auto-
negotiation speed.
SSID：SSID (Service Set Identifier) is the unique name of the wireless network. Wireless client
must input the same SSID to access.
Channel: Specify the effective channel (from 1 to 13\Auto) of the wireless network.
Broadcast (SSID): Select “Disable” to disable the device’s SSID to be invisible by the wireless
client. If you disable it, client must input the same SSID as the device to access.
BSSID: Basic Service Set Identifier of wireless network. In IEEE802.11, BSSID is the MAC address
of wireless access point.
Extend Channel：To increase data throughput of wireless network, the extension channel
range is used in 11n mode.
Channel Bandwidth：Select the channel bandwidth to improve the wireless performance.
When the network has 11b/g and 11n clients, you can select the 40M; when it is an 11n
network, select 20/40M to improve its throughput.
Click “Next” to save configurations.
Note: We suggest you do not change the channel in this mode, or else you can not access the
device which you want to connect.
12. Wireless Security Settings
