Pulse Trigger
• Pulse trigger means determining the triggering time based on the pulse width. You
can acquire abnormal pulse by setting the pulse width condition. Adjust using the
MULTIPURPOSE control.
Functions Menu Setup Notes
Type Edge
Signal source
selection
CH1, CH2
CH3, CH4
EXT, EXT/5
LINE
CH1 & CH2
CH3 & CH4
Set CH1, 2, 3 or CH4 as the signal source trigger signal
Set the external trigger input channel as the signal source
Set to AC power trigger
CH1 & CH2 trigger their respective signals alternately
CH3 & CH4 trigger their respective signals alternately
Grid
Alternate
Set up as grid trigger
Ch1, CH2 trigger their own signals alternatively
Inclination
Rising
Falling
Rise & Fall
Set to trigger on the signals rising edge
Set to trigger on the signals falling edge
Set to trigger on the signals rising and falling edge
Trigger Mode
Auto
Normal
Single
Set to sample waveform only if no trigger condition is
detected
Set to sample waveform only if trigger condition is satised
Set to sample waveform once when detecting one trigger
and then stop
Trigger coupling
DC
AC
H/F reject
L/F reject
Allow AC and DC quantities of the input signal to pass
Intercept DC quantities of the input signal
Reject high frequency quantities above 80kHz of the signal
Reject low frequency quantities below 80kHz of the signal
Functions Menu Setup Notes
Type Pulse
Trigger source
CH1, CH2
CH3, CH4
EXT, EXT/5
LINE
CH1 & CH2
CH3 & CH4
Set CH1, 2, 3 or CH4 as the signal source trigger signal
Set to external trigger or divide the external trigger by 5
Set to AC power source
CH1 & CH2 trigger their respective signals alternately
CH3 & CH4 trigger their respective signals alternately
Pulse width
condition
Larger
Smaller
Equal
Trigger when pulse width is larger than default value
Trigger when pulse width is smaller than default value
Trigger when pulse width equals to default value
Trigger polarity
Pos pulse width
Neg pulse width
Set positive pulse as the trigger signal
Set negative pulse width as the trigger signal
Trigger mode
Auto
Normal
Single
The system automatically samples waveform data
when there is no trigger signal input. The scan baseline
is shown on the display. When the trigger signal is
generates it automatically turns to trigger scan.
The system stops acquiring data when there is no
trigger signal. When the trigger signal is generated
trigger scan occurs.
One trigger will occur when there is an input trigger
signal. Then trigger will stop.
