37
Maintenance(3)
B. Replacing the Battery (see figure 8)
Warning
To avoid false readings, which could lead to
possible electric shock or personal injury,
replace the battery as soon as the battery
indicator “ ”appears.
To replace the battery:
1. Disconnect the connection between the test
leads and the circuit under test, and remove
the test leads from the input terminals of the
Meter.
2. Turn the Meter to OFF position.
3. Remove the screw from case bottom, and
separate the case bottom from the case top.
(figure 8)
SCREW
Model 72-7765: OPERATING MANUAL
