Tenma 72-9380A - AC Current Specifications

16
AC Current (AC+DC measurement is available)
Range Resolution Bandwidth Accuracy
Overload
Protection
400 μA 0.01 μ A
45Hz~1kHz
1kHz~10kHz
±(0.7%+15)
±(1%+40)
0.5A, 1000V fast
type fuse Ø10.3
x 38mm
4000 μA 0.1 μ A
400 mA 0.001mA
400 mA 0.01mA
10A 0.001A
45Hz~1kHz ±(1.5%+20) 10A, 1000V fast
type fuse Ø6.3 x
32mm
1kHz~10kHz ±(5%+40)
Resistance
Range Resolution Accuracy Overload Protection
400 Ω 0.01 Ω ±(0.3%+8) +test leads
OC value
1000V
4k Ω 0.0001 kΩ
±(0.3%+8)
40k Ω 0.001 kΩ
400k Ω 0.01 kΩ ±(0.5%+20)
4m Ω 0.0001m Ω ±(1%+40)
40m Ω 0.001 mΩ ±(1.5%+40)
Continuity Test
Range Resolution Overload Protection
0.01 Ω 1000V
• Open circuit voltage approximate -1.2V.
• The buzzer does not sound when the test resistance is >60 Ω
• The beeper sounds continuously for open circuits and if test resistance is ≤40 Ω
Diode Test
Range Resolution Overload Protection
0.0001 V 1000V
• Open circuit voltage approximate 2.8V.
• A good silicone junction drops between 0.5V and 0.8V
• True rms are valid from 10% of range to 100% of range
• AC crest factor can be up to 3.0.
• A residual reading of 80 digits with test leads shorted, will not affect stated accuracy.
• When frequency is lower than 100kHz, the accuracy guarantee range 10% -100%
• For AC+DC measurement, add (1%-35 digits) of reading based on above table.
• When the measured current is ≤5A, continuous measurement is allowed.
• When the measured current is between 5A-10A, continuous measurement must
be ≤10 seconds and interval more than 15 minutes.
