8
TeNMARS
TM-196
LCD Description
1. Primary Display
2. Ho ld symbol
3. Analogue bar graph
4. MAX symbol
5.
AVG symbol
6. Low battery symbol
7. x1x10x100 unit
8. X.Y.Z unit
9. ALARM sound
10. mV/m, V/m (E)
11 . ~Al m ,Alm unit (H)
12. ~W/m2/ ~W/cm2unit
13. E Symbol
14 . Auto power off symbol
EN -9
15. Time unit
(month: day)
(hour: minute)
(second)
16. MEM reading
symbol
17. SET symbol
18. REC symbol
19. CAL symbol
20. Secondary
Display
21. BUZZER symbol
22. Decimal point
TeNMARS TM-196
9 Specifications
9.1 General specifications
• Display type: Liquid-erystal (LCD), 4-1/2
digits maximum reading 19999.
• Measurement method : Digital, Tri axis
measurement.
• Direetional eharaeterist
ie : Isotropie, Tri
axis.
• Measurement range seleetion: one
eontinuous range.
• Display resolution: Display
resolution:0.1 mV/m, 0.01 V/m, 0.1IJAlm,
0.1 mAlm,0.001 IJW/ m
2
, 0.01mW/ m
2
,
0.001IJ
W
/
em 2
• Setting time: typieally 1.5s (0 to 90%
measurement value.)
• Sampie rate: 1.5 times per seeond.
• Sam pie rate: 3 times per seeond.
• Audible alarm: Buzzer.
• Units: mV/m, V/m, IJAlm, mAlm,
IJW/ m
2
,
mW/m
2
,
IJW/em
2
• Display value: lns tClntaneous measu re d
value, maximum vaiUe, average value,
or maximum average value.
• Alarm fu
ne tion : adjustable threshold
with ON / OFF
EN-10
