TM-6002
EN-6
1. LCD display.
2. PASS LED ：To indicate the tested battery complies with the high limit of
comparator.
3. WARNING LED：To indicate the tested battery is going to deteriorate.
4. FAIL LED：To indicate the tested battery has deteriorated.
5. key ：Comparator function.
6. key ：Average function.
7. key ：To show the data logged readings.
8. key ：To delete single data logged reading in the memory and
settings date/time.
9. key ：Select the impedance range. (40mΩ, 400mΩ, 4Ω, 40Ω)
10. key ：Select the voltage range. (4V, 40V)
11. key ：Power ON/OFF.
12. HOLD key ：Hold or disable -hold function for the displayed values.
13. key ：Turn the beeper on or off
14. key ：For recording the displayed values.
15. key ：For implementing the zero-adjust feature.
16. key ：Select the auto-hold and auto-memory feature.
17. key ：For configuration settings and changing their values.
18. key ：To set the configuration with entering values.
19. SOURCE＋ input jack：For connecting with the red test lead plug.
20. SOURCE－ input jack：For connecting with the back test lead plug.
21. SENSE＋ input jack：For connecting with the yellow test lead plug.
22. SENSE－ input jack：For connecting with the blue test lead plug.
23. TEMPSENSOR input jack：For connecting the plug of the temperature
sensor.
24. DCA＋ input jack：For connecting with the red test lead plug to current
probe.
25. DCA－ input jack：For connecting with the back test lead plug to current
probe.
26. USB interface：Used for connecting the USB cable.
27. DC input jack：Used for connecting the external power DC 9V input.
4. Electrical specifications:
To ensure accuracy the ambient temperature should be 23°C ± 5°C
with a humidity of 80% RH (maximum) non-condensing. In addition,
