1
a
b
2
a
b
c
Tools needed: No.5 hex key and
No.3 hex key
01
Remove the clamp block from the
front brake clamp, install the brake
clamp on the brake seat of the front
fork, place the brake disc in the middle
of the brake clamp, and tighten with
the No.5 hex key. Torque: 8-10 Nm.
02
Route the hydraulic cable along the
bottom of the front frame and fasten
with cable ties.
019 Assemble your TENWAYS e-bike
06.
INSTALL THE FRONT BRAKE CLAMP
