Description of product
LAP-TEQ PLUS 13
A complete LAP-TEQ PLUS angle measuring system consists of a display unit
and at least one sensor unit.
The sensor unit is designed for mounting on the topmost element of a line
array or of the bumper and measures the horizontal angle between its
longitudinal axis and the earth’s surface. This provides information on the
horizontal orientation of the speaker element and/or of the entire array.
The laser beam of the sensor unit is used for visually checking the area that is
supplied with sound. This allows you to determine whether the height of the
speaker system is optimally adjusted in order to distribute sound to a spectator
stand or a balcony.
If the laser beam hits a projection surface at a short distance, in addition to the
actual laser cross you will also be able to see a square window and several
points in extension to the cross axis. These artefacts are no longer visible with
the normal working distances of the system and do not constitute a defect.
The products LAP-TEQ Display, LAP-TEQ Sensor, LAP-TEQ Display PLUS
and LAP-TEQ Sensor PLUS are mutually compatible and can be operated
together in any combination.
LAP-TEQ Sensor is limited to operation with the base plate oriented
downward.
The calibration of a sensor unit from the display unit is possible only with the
combination LAP-TEQ Display PLUS and LAP-TEQ Sensor PLUS.
For calibration of LAP-TEQ Sensor PLUS without LAP-TEQ Display PLUS
please contact your sales partner.
Compatibility overview
Operation Calibration Operation Calibration
Display Yes Internal Yes No
1
Display PLUS Yes Internal Yes Yes
1
Contact service partner
