• Mount the Bolt transmitter vertically, keeping the
antennas clear of any obstructions.
• Orient the transmitter and receiver antennas so
they are parallel to each other.
• For best results, orient the transmitter antennas
so each one has clear line−of−sight to the
receiver.
DO NOT OVERTIGHTEN
SCREWS INSERTED INTO
THE 1/4”-20 OR 3/8”-16 THREADED HOLES.
Doing so can damage the transmitter’s chassis
and internal components, voiding the warranty.
Bolt 4K LT devices have a 1/4”-20 threaded hole (additional 3/8”-16 threaded hole on the receiver) on
the bottom for mounting the included light stand adapter or any other mounting accessory.
Bolt 4K LT receivers
can be mounted
vertically on a light
stand or monitor.
MOUNTING
CAUTION:
Bolt 4K LT
transmitters
mount vertically
on a camera.
6
