Connect the motor to Latitude using a 4-pin connector. If connecting two motors, use a Y-cable
4-pin connector to connect both motors. The motor(s) will then begin calibrating.
2
3
Attach the motor(s) to the rods/lens.
Connect power to Latitude’s PWR port (N).
1
There are two pairing methods if the controller is new or has not been paired to a receiver.
Insert an LP-E6 battery in the controller and hold down the POWER button for two seconds. If
using a Latitude MB, you must also insert an LP-E6 battery into the unit.
4
Press the MENU button on the controller, then navigate to WIRELESS>FIND RECV to scan for active
receivers and automatically pair. The LED on the controller will turn green once paired.
Wireless Pairing
Connect a 5-pin connector from the controller’s wired-mode input (H) to the IN-1 input on Latitude.
The controller and receiver will remain paired even after disconnecting the 5-pin connector. The LEDs
on the controller and receiver will turn blue once paired.
Wired Pairing
3
PAIR CONTROLLER AND RECEIVER
POWER AND CONNECT
